SPARTNA SPR-612 Differential Pressure Manometer

SpartnaSKU: SPR-612
filler

Price:
Sale priceAED. 980.00
Stock:
Sold out

Description

The SPR-612  is a precision differential pressure manometer capable of measuring gauge and differential pressures in a wide range of applications. It supports 11 selectable units of measurement, making it versatile for use across various industries. Designed for accuracy and reliability, the device features a dual LCD display, data hold functionality, and an automatic power-off feature (can be disabled).


  • Multi-Unit Support: Offers 11 selectable units of measurement: inH₂O, psi, bar, mbar, kPa, inHg, mmHg, oz/in², ftH₂O, cmH₂O, kg/cm².
  • Data Hold Functionality: Freezes the displayed reading for easy reference.
  • Auto Power Off Disabled Option: Can disable the auto power-off function for extended usage.
  • Dual LCD Display: Provides clear and accurate readings with unit indicators.
  • Zero Adjustment & Offset Measurement: Allows zero calibration and offset measurements.
  • Record Mode: Stores MAX, MIN, and AVG readings with relative time stamps.
  • Backlight Display: Enhances readability in low-light conditions.
  • Over/Under Range Indicators: Alerts users when measurements exceed or fall below operational limits.
  • Low Battery Indicator: Notifies users when battery replacement is needed.

Specification Details
Measurement Range -138.4 inH₂O to 138.4 inH₂O / ±5 psi
Units Supported inH₂O, psi, bar, mbar, kPa, inHg, mmHg, oz/in², ftH₂O, cmH₂O, kg/cm²
Display Dual LCD
Accuracy ±0.3% FSO at 25°C
Repeatability ±0.2% Max / ±0.5% FSO
Linearity/Hysteresis ±0.29% FSO
Maximum Pressure 20 psi
Response Time 0.5 seconds typical
Operating Conditions 0 to 50°C
Storage Conditions -10 to 60°C
Power Supply 3 x 1.5V AAA batteries
Low Battery Indicator Yes
Over-Range Indicator Err.1
Under-Range Indicator Err.2
Auto Power Off After 20 minutes of inactivity (can be disabled)

Downloads

SPR-612 Datasheet
