SPARTNA SPR-214 AC/DC TRMS H&W Analysis Clamp Meter

SpartnaSKU: SPR-214
filler

Price:
Sale priceAED. 750.00
Stock:
Sold out

Description

The AC/DC TRMS H&W Analysis Clamp Meter is a high-performance digital clamp meter designed for accurate electrical measurements in industrial, commercial, and residential applications. It combines True RMS measurement technology with harmonic analysis capabilities, making it ideal for analyzing complex waveforms in modern electrical systems. The device features a large jaw opening, Bluetooth connectivity, non-contact voltage detection, and multiple measurement functions including current, voltage, resistance, capacitance, temperature, harmonics, and power.


  • True RMS Measurement : Ensures accurate readings for both sinusoidal and non-sinusoidal waveforms.
  • High Current Measurement : Measures up to 2000A DC or 1500A AC with a large 2.3" (60mm) jaw opening.
  • Voltage Measurement : Measures AC/DC voltage up to 1000V with high input impedance.
  • Power & Harmonic Analysis : Measures active power (W), power factor (PF), total harmonic distortion (THD), and individual harmonics up to the 25th order.
  • Resistance & Continuity Test : Includes continuity buzzer for quick circuit checks.
  • Capacitance Measurement : Supports capacitance testing up to 9999µF.
  • Temperature Measurement : Supports Type K thermocouples for temperature measurement (-20°C to 1000°C).
  • Non-Contact Voltage Detection : Detects live conductors without direct contact.
  • Data Hold & MAX/MIN Mode : Captures and stores peak values for analysis.
  • Auto Ranging & Manual Range Selection : Offers flexibility for different measurement scenarios.
  • LCD Backlight & Flashlight : Improves visibility in low-light conditions.
  • Bluetooth Connectivity : Enables wireless data transfer to smartphones or tablets.
  • Overload Protection : Designed with double insulation and overvoltage protection (CAT II 1000V / CAT IV 600V).
Parameter Details
Current Measurement (AC) Range: 60.00A – 1500A; Accuracy: ±(2.5% + 5 digits)
Current Measurement (DC) Range: 60.00A – 2000A; Accuracy: ±(3% + 5 digits)
Voltage Measurement (AC/DC) Range: 6.000V – 1000V; Accuracy: AC ±(1.2%–1.5% + 5 digits), DC ±(1.0%–1.5% + 3 digits)
Active Power (AC) Range: Up to 1000kW; Accuracy: ±(3% + 3 digits)
Power Factor (PF) Range: -1.00 to +1.00; Accuracy: ±3° ±2 digits
Resistance Range: 600Ω – 60MΩ; Accuracy: ±(1.0%–4.0% + 3–5 digits)
Capacitance Range: 9.999µF – 9999µF; Accuracy: ±(3.0%–4.5% + 5–10 digits)
Frequency (AC Voltage) Range: 20.0Hz – 9.999kHz; Accuracy: ±(1% + 3 digits)
Duty Cycle Range: 0.1% – 99.9%; Accuracy: ±(1% + 3 digits)
Total Harmonic Distortion (THD) Range: Up to 99.9%; Accuracy: ±(5% + 3 digits) @ 50/60Hz, >100Vrms
Individual Harmonics Range: H01–H25; Accuracy: H01–H12 ±(5% + 3 digits), H13–H25 ±(20% + 3 digits)
Temperature (Type K) Range: -20°C to 1000°C (-4°F to 1832°F); Accuracy: ±(3% + 5°C or 9°F)
Display 3-6/7 Digit (6000 counts), Backlit LCD
Sampling Rate 3 readings per second
Input Impedance 10MΩ (for VDC and VAC)
Crest Factor Not specified
Clamp Jaw Opening 2.3" (60mm)
Overvoltage Protection CAT II 1000V / CAT IV 600V
Safety Standards IEC/EN 61010-1; Double Insulation, Pollution Degree 2
Power Supply 3 x 1.5V AA Batteries
Auto Power Off After approx. 15 minutes of inactivity
Dimensions Not specified
Weight Not specified
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity (Operating) Max 80% RH up to 31°C (87°F), linearly decreasing to 50% RH at 40°C
Approvals CE Marked

SPR-214 datasheet
